Teraflex Rzeppa High-Angle CV Driveshaft Front 3-6in Lift

Teraflex High-Angle Rzeppa CV Driveshaft Features:

Rzeppa style joint allows for smooth torque transfer regardless of joint angle

High-angle CV housing design supports larger lift heights and maximum articulation w/out joint damage

Laser welded 2-3/8" carbon steel tubing for superior strength and longevity

Precision construction reduces harmonic vibration for smoother high RPM dynamics

Torque and fatigue tests are 3x higher than OE and aftermarket steel driveshafts

Rzeppa and sealed boot slip spline section provides years of maintenance free operation

Black Trivalent Zinc Chromate Coating for improved corrosion resistance

Double hobbed CNC spline surfaces meet OEM strict tolerance specs

Blue PA11 anti-friction coating applied to splines ensuring 360-degree coating thickness for long life and low maintenance

Red Line full synthetic high-temperature resistant CV grease resists liquefying for consistent performance across all temperatures


Ultimate Performance and Handling
Whether you are adding convenience features to your modified Jeep Wrangler JK or installing a new performance upgrade, a genuine Teraflex Rzeppa High-Angle CV Driveshaft is the perfect complement. The unique construction and final assembly with precise double studs provide a true centric assembly without need for balance weights. Unlike a U joint style driveshaft, the Rzeppa CV Joint does not experience a significant loss in strength due to high angles, making it ideal for both street and off-road applications. without sacrificing the benefits. This is especially important on 3+" lifted Jeep JK Wrangler where a longer wheelbase requires a more versatile replacement driveline component.



Flaws Found in Factory Style Driveshaft Addressed
  Combine the smooth torque transfer of a CV joint with a High-Angle Rzeppa CV Driveshaft. This unique package is engineered for the extreme angles associated with larger lift heights, lower front beds, and off-road applications. The design features a 2D composite inner boot that mates to a double steel outer boot providing superior structural support and protection against shear forces. This unique combination allows for ease of installation and maintenance on lifted rigs, heavy equipment, front-end loaders, and crawlers hauling work equipment at high elevations. Using laser welded 2 - 3/8" carbon steel tubing results in superior strength and longevity. Precision construction reduces harmonic vibration for smoother high RPM dynamics.

Note(s):

Front High-Angle Rzeppa CV Driveshafts do NOT work w/ manual transmission.

CV Driveshafts require TeraFlex JK: High-Angle Rzeppa CV Yokes:

Transfer Case Yoke – Front or Rear (# 1959110)

Axle Pinion Yoke – Front – 24-Spline (# 1959210)

Axle Pinion Yoke – Rear – 24-Spline (# 1959310)

Dana 60 Pinion Yoke – Front or Rear – 29-Spline (# 1959400)
