AFE Power Sprint Booster Power Converter

Automobiles in the 21st century have replaced the more conventional throttle cable technology for an ECM (Electronic Control Module) that translates pedal travel into electronic signals in order to provide power to the wheels. The ETC system (Electronic Throttle Control) – also known as drive-by-wire – has the unfortunate downside of delayed throttle response and subdued acceleration, creating problems in certain circumstances such as up-hill starts, quick gearchanges, overtaking, etc. The Sprint Booster aims to overcome this throttle response delay for ETC-equipped vehicles, providing crisp on-tap acceleration at the driver’s disposal.

Simple plug and play Installation
For vehicles with electronic control (ETC) systems, or drive by wire, this device plugs into the OE connector located behind the accelerator pedal. It is a simple installation, requiring no cutting of any wires or intervene in the automobile’s electronics (it does not affect other systems such as electronic injection, ABS, etc.

Three acceleration modes

OFF MODE – Sprint Booster is deactivated. The response of the car has the factory settings. The LED of the Selector switch is OFF. SPORT MODE – Sprint Booster provides improved response up to 30%.The LED of the selector switch in Sport mode is Green. RACE MODE – Sprint Booster provides improved response up to 60%. The LED of the selector switch in Race mode is Red. The modes are switching by pressing the main button (black chromed button with log)

36 Accelerations programs
Each Acceleration mode comes with 9 programs / steps, Select 1-9 in SPORT mode (Green light) and 1-9 in RACE mode (Red light) with '1' being the least aggressive program and '9' the most aggressive one. The Acceleration programs are switching by pressing the 2 arrow buttons on the top (left to decrease and right to increase). By selecting the desired acceleration program in each mode the driver can fine-tune each mode according his driving style (eg select SPORT -9 & RACE-5).

Works for both automatic and manual transmission
Sprint Booster modes and programs, are transmission type specific for better function and performance. The driver can select the type of his vehicle transmission through a slide switch located on the right side of the selector switch. The device will automatically adjust the programs according the type of transmission selected. There are 36 programs in total (18 for manual transmission & 18 for automatic transmission).

Valet and pedal lock modes
Valet mode limits the acceleration of the vehicle by 55 % - 65% - 75% (comes in 3 selectable levels). It is activated/deactivated through a 3 digit PIN. By limiting the acceleration there will be a significant reduce in vehicle's performance (Power and Torque). The Pedal Lock mode provides extra protection against unauthorized vehicle use. The driver can deactivate the acceleration ability of the vehicle through a 3 digit PIN. The menu for VALET & PEDAL LOCK MODE is accessed when the vehicle is stationary and in OFF MODE by pressing the 2 arrow buttons simultaneously.

Better Drivability
In addition to the increased throttle response and the improved acceleration, there is also a noticeable difference in the transmission shifts (for vehicles equipped with Automatic transmissions). It also improves response for downshifts and safer overtaking.
