Rock Hard 4x4 Patriot Series Rear Bumper w/ Tire Carrier - JL

Exterior
Bumpers
Rear Bumpers >Rock Hard 4x4 Patriot Series Rear Bumper w/ Tire Carrier - JL

Rock Hard 4x4 Patriot Series Rear Bumper w/ Tire Carrier

Name: Rock Hard 4x4 Patriot Series Rear Bumper w/ Tire Carrier
Brand: Rock Hard 4x4
SKU: RH-90301
Price: 1749.95 USD
Availability: OutOfStock
Rating: 5 (3 reviews)

JL

★★★★★

(5)
Read 3 Reviews | Q&A

Part # RH-90301

$1,749.95

Quantity

Out of stockProduct will ship from manufacturer, average time to ship: 3-5 business days

Qualifies for
free shipping!

Set your vehicle to confirm fitment

You will earn Reward Points with this Purchase.

Authorized
Dealer

Product Resources

Installation Instructions

Customer Reviews (3)

Fitment Details

Features & Product Details

We believe armor should be stronger than the vehicle. We believe upgrades should be heavy duty, premium, and easy to install. If you do too, the ultimate rear bumper with tire carrier for the Wrangler JL is here! Fully loaded and incredibly strong, the Patriot Series Rear Bumper with Tire Carrier RH-90301 retains every single factory option moved to a 1/4" thick steel armor upgrade. Frame mounted takes the weight off your JL's body giving you the option to add accessories plus extends the life of your tailgate. 100% bolt-on installation makes removing your factory bumper and upgrading to a Patriot Series rear bumper doable by any level installer.

FEATURES:

1/4" thick plate steel

100% bolt-on design

Frame mounted bumper/tire carrier (zero weight on tailgate/body)

Adjustable spare tire mount

Back-up camera compatible

Parking sensor compatible (grommets included)

Plastic plugs included if not sensor equipped

Integrated 2" tow-rated receiver

Hi-Lift jack mount included (with security cable tab)

CB antenna mount included

3rd brake light compatible

Integrated safety chain attachments

High clearance tapered sides

Towing electronics port provision (block off plate included)

1" thick double welded recovery tabs included

Powder coat included

All hardware included

Specifications

Weight: 150 lbs.

40" tire rated (38" with cargo basket/tank mounts)

Width: 70"

Construction

Rock Hard 4x4's proprietary dual-stage latching mechanism and "pre-load" design prevent vibration and wobbling to help ensure whether you are on the toughest off-road trail or loading gear into the back of your Jeep.

The secret to their tire carrier's success is their in house designed and constructed serviceable hub assembly. Instead of a single bearing we use dual tapered bearings for smooth and consistently reliable operation. RH4x4's dual-stage latch operates just like a car door with a safety catch to prevent accidental swing gate opening. Operation is effortless.

Product Video

Product Resources

Installation Instructions

Customer Reviews (3)

Fitment Details

Specifications

Brand: Rock Hard 4x4

Bumper Style: Full Width

Color: Black

Finish: Powder Coat

Lights Included: No

Material: Steel

Material Thickness: 1/4in

Tire Carrier Included: Yes

Back Up Light Option: Yes

Fog Light Mount: No

Tire Capacity: 40.00in

Mfgr. Warranty: Limited Lifetime

Condition: New Product

Return Policy:

Standard

REVIEWS & CUSTOMER MEDIA

★★★★★

3 Reviews

5 out of 5 Stars

5 Stars

(3)

4 Stars

(0)

3 Stars

(0)

2 Stars

(0)

1 Stars

(0)

Customer Photos and Videos

No user media. You can upload a photo or video of your install by posting a review.

Awesome rear bumper and tire carrier 2 years ago

5out of 5stars

2 TJ, 1 JL family
Upgraded to 35" tires and needed to go with an upgraded tire carrier to accomodate them. Already had a RH payriot bumper and was majorly impressed. Went with this and was not let down. RH is 2 for 2. Installed it myself, helps to have a friend or platform jack due to weight. Fit and finish is top rate. All bolt holes lines up perfect, Looks real nice and allows for even larger tires no prob. Nothing chinsy on it, all well-built and very solid.

Was this review helpful?
Sign In to vote!

Strong and Looks good 2 years ago

5out of 5stars

BigRu
The install does take a bit longer than you would think but if you are not in a rush and things go your way it can be done in a day in the garage. The spare is higher than stock so the third brake light is as well. Looks good and strong with everything fitting precisely for me with a couple trips to the hardware store for the inevitable customized fit with each individual and anything out of the ordinary. Customer support is beyond helpful and courteous. Definitely recommend

Was this review helpful?
Sign In to vote!

Rock solid, heavy AF. 2 years ago

5out of 5stars

Fusco
It works well. Had it installed on Rubicon JLU and it would crush rocks before taking damage. Thick... There is some maintenance requirements with adjusting swing gate, greasing the hinge, etc. but nothing unreasonable. I installed on my own but would recommend having assistance with the lifting and adjustments.

Was this review helpful?
Sign In to vote!
